Vehicle Spectroscopic Monitoring – Radcomm RC-7000 Series

Vehicle Spectroscopic Monitoring – Radcomm RC-7000 Series

System designed to detect and identify radioactive materials contained in a moving vehicle loaded with dense material (Metal recycling). The complete system consists of detector assemblies (1 to 5 panels), infrared presence sensors, Window based controller, large touch-screen monitor, printer and all required drawings (installation, concrete base, electrical).

• Compliant to ANSI N42.38 / IEC 62484, ANSI N42.42 / IEC 62755.
• Energy range: 20 KeV to 3.3 MeV.
• Large Sodium Iodide thallium doped crystal detectors (NaI(Tl)) 16" x 4" x 2" (405mm x 102mm x 50mm).
• Energy resolution: 8% or better at 662 keV.
• Detection/identification sensitivity: meets ANSI N42.38 (2006) / IEC 62484.
• System can be calibrated for specific isotopes.
• Software with detailed alarm information (positioning); data storage (alarms and clean); remote calibration, service and monitoring; multi-level security password control and multiple languages.
• Email ready for sending alarms and errors.
• Maximum speed: 20 km/h.

 OPTIONS

• Installation and training.
• Detector supports (single leg) with or without bollards.
• Neutron detector (He3 or alternative).
• Wireless package.
• External alarms (light and/or buzzer).
• Supervisory software for remote monitoring (1 or multiple portals).



• • RC7000-1: One NaI(Tl) crystal detector.
  • RC7000-2: Two NaI(Tl) crystal detectors. Detection capability/sensitivity calibrated for specific isotopes.
  • RC7100-2: Two detectors - NaI(Tl) crystal with neutron. Detection capability/sensitivity calibrated for specific isotopes.
  • RC7138-2: Two detectors – NaI(Tl) crystal with PVT. Detection capability/sensitivity calibrated for specific isotopes.
